    OK so after letting it slip that I am working on a new concept the "Leviathan" I have received a TON of emails and questions so here is the sneak peek at how I go about designing a fixed blade knife.

    Here are the parameters/design goals for this design:

    7" Large hunter/fighter sized blade with full tang
    Open to different blade geometries
    Use .21" surface ground CPM-3V steel (A perfect middle ground thickness between a fast in the hand 3/16" fighter and a 1/4" survival/chopper)
    Incorporate a "harpoon" blade design element
    Incorporate a sub-hilt handle design element
    Use custom CNC routed handels
    Provide a custom etched Leather/Kydex hybrid sheath with Tec-Loc attachment system

    So with these ideas in mind I quickly drew out the rough idea in CAD. I started with the classic blade to handle ratio of a great old standby design, the KA-BAR Mark 2. It's a reliable place to start.

    My first concept hits all the design criteria above but frankly looks but ugly and uncomfortable. I try to play with an idea of combining two blade forms I have come to love the harpoon false edge and a Wharncliffe blade geometry. Ya it"s a bit unorthodox but I thought that a little experimentation I could refine the look...


  2. #2
    Ill take it
    WTB- Les George Rockeyes small, regular, and extra large. If you have one and want entertain the idea of getting rid of it... LET ME KNOW!

  3. #3
    Join Date
    Apr 2011
    Location
    Savannah, GA
    Posts
    452
    Next step is to work in sets of "iterative concepts" making incremental changes to the form. I find the best way for me to see how I feel about a design is to actually hold it. Thats where laser cut technology come to the rescue. I can draw out designs and have a laser cut blanks from foam core to test the ergonomic value and aesthetic appeal of each design.





  4. #4
    Just throw one in with my TiTan, I will let you know how it is . But just my 0.02 I would buy #1 or #4. I like those shapes the most.
    WTB- Les George Rockeyes small, regular, and extra large. If you have one and want entertain the idea of getting rid of it... LET ME KNOW!

  5. #5
    Join Date
    Apr 2011
    Location
    Savannah, GA
    Posts
    452
    As you can see from the photos. I cut out a design, modify that, test it, make changes, cut a new design, and then compare the two. In 3 hrs I can test more than a dozen designs on a $2 sheet of foam core. Try that with steel or hand cutting cardboard. In my testing I found a 5 degree tilt to the handle to be superior for cutting tasks and swinging tasks. It just felt....right. Here I also settled on chain bolts to fasten the CNC handles.

    The pictures are in chronological order from the first concept to last




  6. #6
    Join Date
    Apr 2011
    Location
    Savannah, GA
    Posts
    452
    Quote Originally Posted by Windex_ View Post
    Just throw one in with my TiTan, I will let you know how it is . But just my 0.02 I would buy #1 or #4. I like those shapes the most.
    We sir, are in sync.

    I finally chose two blade shapes that felt great in the hand and also fulfilled the original design criteria. These two designs will be offered as "Leviathan's".

    The Harpoon Wharncliffe will feature a sharpened top edge more suitable for offensive/defensive cutting tasks.
    The Harpoon Drop Point will feature a false top edge to aid in outdoor/survival knife duties.

    Two knives. Two personalities. One soul.

    I will not begin taking pre orders till I have finished with the TiTAN order. For those of you that have already asked: If you want the most up to date info on getting your hands on a Leviathan, just subscribe to this thread and Ill answer any questions.





    The $20 bill is for scale and will not be included in ANY purchase.


  7. #7
    Join Date
    Apr 2011
    Location
    Savannah, GA
    Posts
    452
    Example of my custom etched Leather/Kydex hybrid sheath with Tec-Loc attachment system.
